Cisco Room Kit Pro G2
The Room Kit Pro G2 is a modular system for large conference rooms, boardrooms, auditoriums, and divisible spaces, built around the NVIDIA-based Cisco Codec Pro G2. The codec's room engine drives AI camera modes, audio processing, and multi-source switching, and it orchestrates AV-over-IP so cameras, microphones, and displays can be placed anywhere in the room.
The bundled Quad Camera uses four image sensors up to 20 megapixels each with machine-intelligent switching, 7x zoom, and an eight-element microphone array for framing. The codec brings five HDMI 2.0 inputs, three HDMI outputs, up to five video-over-IP streams, and four balanced microphone inputs with phantom power and per-input echo cancellation. It runs RoomOS 26.5 and supports optional PTZ and additional cameras for multi-camera productions.
| Codec | Cisco Codec Pro G2, NVIDIA-based room engine |
|---|---|
| Camera | Quad Camera, 4 sensors up to 20 MP, 1/1.7\" CMOS, 7x zoom, f/2.0 |
| Camera Mics | 8-element array for intelligent framing |
| Video Inputs | 5x HDMI 2.0 (up to 5120 x 2160), up to 5 video-over-IP streams |
| Video Outputs | 3x HDMI 2.0 |
| Audio Inputs | 4x mic/line, 48V phantom, Euroblock; per-input echo cancellation |
| Software | RoomOS 26.5; H.264 / H.265 / AV1 |
| Power | PoE budget up to 120 W across 8 ports; 270 W codec supply |
