BZBGear BG-UHD-VWP19 Multi-Format Video Wall Processor for Nine Displays

The BG-UHD-VWP19 is the multi-format processor in the line: HDMI, DisplayPort 1.4, USB-C, VGA, YPbPr and CVBS inputs all feed one wall, at up to 4K60 YUV 4:4:4. Nine HDMI outputs drive the displays with a tenth as a loop out for local monitoring.

Content can be resized, rotated and positioned to build layouts such as a 3x3 in full 4K, and layouts are held in onboard memory for recall. Seamless switching, scaling and EDID management are all handled inside the unit. Audio is available on stereo and S/PDIF, and control is by front panel, IR remote or software.

HDCP Compliance	Yes
Video Bandwidth	Input: Single-link 600 MHz (18 Gbps) Output: Single-link 600 MHz (18 Gbps)
Video Format Support	HDMI / DisplayPort / VGA / YPbPr / CVBS / Type-C
Input	1 x HDMI 1 x DisplayPort 1 x USB 3.0 Type-C 1 x VGA 1 x YPbPr 1 x CVBS 2 x Stereo 1 x SPDIF 1 x USB 2.0 Type-A 1 x RJ45 1 x 3.5mm IR 1 x Micro USB
Output	10 x HDMI 1 x Stereo 1 x SPDIF
Control	Front Panel / IR Remote / Software Control
Power Supply	12V DC
Power Consumption	50 W (max)
