Bose Professional Bose EdgeMax EM180-LP Low-Profile Loudspeaker

The EdgeMax EM180-LP is the low-profile version of Bose Professional's wide-coverage EdgeMax ceiling speaker, built around a 5.25-inch woofer and a 1.3-inch compression driver in a two-way passive design. Its PhaseGuide technology throws a 180-degree horizontal pattern from an edge or corner mounting position, which is what makes it a fit for hallways and room perimeters where a center-ceiling speaker would waste half its pattern into a wall.

It is finished in paintable white (similar to RAL 9003) and its shallow 3.9-inch enclosure depth clears plenum spaces a deeper woofer can't fit.

TypeLow-profile edge-mount ceiling loudspeaker
Drivers1 x 1.3-inch compression driver; 1 x 5.25-inch woofer, 2-way passive crossover
Frequency range (-10 dB)45 Hz - 19,000 Hz
Coverage180 degrees horizontal; 80 degrees vertical
Power handling32 W continuous; 128 W peak
FinishWhite (similar to RAL 9003), paintable
Dimensions13.4 x 13.4 x 3.9 in (339 x 339 x 100 mm) enclosure
Net weight16.7 lb (7.6 kg) with grille
