Blizzard Lighting Komply DMX LED Tape Decoder
The Blizzard Lighting Komply DMX is an LED tape DMX decoder from Blizzard Lighting. It turns DMX into PWM for up to four separate 12V LED ribbon runs or one RGB or RGBW strip, so a lighting console can dim tape the same way it dims fixtures, with 256 grayscale levels per channel. Published output signal: 4 channels @ up to 4A per channel, which is up to 108 W at 12V or 192 W at 24V.
Input dmx signal covers DMX512/1990 digital, over both XLR and RJ45 in and out, and the DMX address is set on DIP switches. Without a console it runs standalone with seven static colors plus an auto mode. Input voltage is quoted at 12V to 24V. Listed dimensions: 1.6" x 2.6" x 6.5" 0.9 lbs. Ordering code KOMPLY DMX.
| Input voltage | 12V to 24V |
|---|---|
| Input DMX Signal | DMX512/1990 digital |
| Output Signal | 4 channels @ up to 4A per channel |
| Output power | 12V:<108W, 24V:<192W |
| Dimensions | 1.6" x 2.6" x 6.5" 0.9 lbs |
| DMX In/Out | RJ45 and |
| Grayscale | 256/channel |
| General Specs | 7x static colors + auto in standalone |
| Addressing | DIP switches |
