Blizzard Lighting Komply DMX-24 LED Tape Decoder
The Blizzard Lighting Komply DMX-24 is an LED tape DMX decoder from Blizzard Lighting for bigger tape installs: it turns a DMX512 signal into PWM across 24 output channels, which is eight separate RGB runs, each dimmed with 256 grayscale levels from a console. Published output: 24 channels @ up to 2A per channel, good for up to 576 W at 12V or 1,152 W at 24V in total.
Input dmx signal covers DMX512/1990 digital, with both RJ45 and XLR DMX in and out, and the start address is set on DIP switches. It works from -24 to 60 C, so it can sit in an outdoor enclosure. Input voltage is quoted at 12V to 24V. Listed dimensions: 2.2" x 5.5" x 13.3" 3 lbs. Ordering code KOMPLY DMX-24.
| Input voltage | 12V to 24V |
|---|---|
| Input DMX Signal | DMX512/1990 digital |
| Output | 24 channels @ up to 2A per channel |
| Output power | 12V:<576W, 24V:<1152W |
| Dimensions | 2.2" x 5.5" x 13.3" 3 lbs |
| Working temperature | -24 to 60C |
| Grayscale | 256 levels/channel |
| Addressing | DIP switches |
| Working Temperature | -24 to 60C |
