Biamp Devio DCM-1 Collaboration Hub

The Biamp Devio DCM-1 is a collaboration hub built for conferencing rooms. Power handling is rated at < 1 W, phantom powered from SCR-20/SCR-25.

Audio: PENDANT MICROPHONE; Microphone Technology: 8-Element Digital Array; Frequency Response (150 Hz - 16 kHz): +/- 3 dB; Polar Pattern: Active Beamformed. In the box: Power: < 1 W, phantom powered from SCR-20/SCR-25; Indicators: Connection Indicator (Green LED). Order it in 2 versions: DCM-1Black, DCM-1White.

Power	< 1 W, phantom powered from SCR-20/SCR-25
Audio	PENDANT MICROPHONE; Microphone Technology: 8-Element Digital Array; Frequency Response (150 Hz - 16 kHz): +/- 3 dB; Polar Pattern: Active Beamformed
Included Accessories	PLENUM BOX (included): Power: < 1 W, phantom powered from SCR-20/SCR-25; Indicators: Connection Indicator (Green LED); Digital Interface: Custom/Proprietary
Ambient Operating Temperature Range	32-104 deg F (0-40 deg C)
Humidity	0-95% relative humidity (non-condensing)
Altitude	0-6,600 ft (0-2000 m) MSL
Dimensions (H x W x D)	Pendant Microphone: 2 inches (51 mm); Plenum Box: 2 inches (51 mm) x Pendant Microphone: 2.5 inches (63 mm); Plenum Box: 4 inches (102 mm) x Pendant Microphone: 2.5 inches (63 mm); Plenum Box: 5.4 inches (137 mm)
Weight	Pendant Microphone: 0.38 lbs (0.17 kg); Plenum Box: 0.86 lbs (0.39 kg)
