AUDAC TRM024 70/100V Transformer Module

The TRM024 is AUDAC's 70/100V transformer module for VEXO206 or VEXO208 at 8 ohms (secondary) over a 50 Hz - 20 kHz response.

It connects by External (to amplifier) - 8-pin terminal block. The housing is Aluminum backplate. Supplied with M8 x 80 mm (mounting bolt).

Line Transformer Tappings 1	20.83 ohms - 100 V / Not used - 70 V / 240 W
Line Transformer Tappings 2	41.67 ohms - 100 V / 240 W - 70 V / 120 W
Line Transformer Tappings 3	83.33 ohms - 100 V / 120 W - 70 V / 60 W
Impedance	8 ohms (secondary)
Connection	External (to amplifier) - 8-pin terminal block
Frequency Response (+/- 3 dB)	50 Hz - 20 kHz
Construction	Aluminum backplate
Compatible devices	VEXO206
