AtlasIED BB-168AECDT 16 Input x 8 Output - Networkable DSP Device with Acoustic Echo Cancellation

The AtlasIED BB-168AECDT is a 16 input x 8 output - networkable DSP device with acoustic echo cancellation. The BlueBridge® BB-168AECDT networkable DSP devices with Acoustic Echo Cancellation and Dante™ is a powerful and flexible tool offering mission critical solutions to successfully satisfy your customers' teleconferencing and video conferencing needs. Engineered to strict standards with the highest quality internal components, BlueBridge® DSP solutions provide pure clean analog and digital audio, Ethernet connectivity for cost effective TCP/IP control and open architecture with Drag and Drop programmability.

AtlasIED offers the widest range of open architecture DSP platform I/O configurations of any manufacturer in the industry, all configured using the same software. The BlueBridge® AEC model with the Dante™ digital audio network chipset offers up to 16 channels of self-configuring, true plug-and-play digital audio over an Ethernet network providing the highest quality audio over existing network infrastructure. AtlasIED lists wide-band acoustic echo cancellation; Dante™ ethernet based digital audio; true plug-and-play digital audio networking; 16x8 I/O configuration. It measures 1.75" (44mm) high, 19" (483mm) wide, and 9" (229mm) deep. It carries a manufacturer warranty of 36 months from date of purchase.

Part NumberBB-168AECDT
Input TypeMic or Line, GUI Selectable
Power Requirement90-240VAC (50-60Hz)
Input Gain-40 to +15dB in 0.25 dB steps
Phantom Power48V, GUI Enabled
Output TypeLine
Output impedance50Ω
RAID40-Bit Floating Point
Sample Rate48kHz
Analog ConvertersHigh Performance 24-Bit
Width19" (483mm)
Height1.75" (44mm)
Depth9" (229mm)
Warranty Period36 months from date of purchase
