AtlasIED AH99-8T-BSG 8" 2-Way Stadium Horn Speaker System 90° x 90°

The AtlasIED AH99-8T-BSG is an 8" 2-way stadium horn speaker system 90° x 90°. AtlasIED model AH99-8T-BSG "stadium horn" is ideal for directional sound distribution where full range reproduction, maximum intelligibility and high sound pressure levels are required. Applications include football stadiums, sports arenas, baseball fields, convention centers and auditoriums. Published frequency response is 90Hz - 15kHz.

A "weep" hole is also included on the back of the large horn "bell" to allow evaporation of any condensation that might build up internally. Learn more about the importance of protecting paging horns from low frequency damage and view the TSD-HF11 unit designed specifically to protect horns from low frequency damage. AtlasIED lists 100 watts power handling; constant directivity design offers controlled coverage of 90° horizontal by 90 ° vertical (2kHz octave band); driver compliment includes 8" cast frame woofer with a concentrically mounted 1" exit compression driver coupled to a 90°H x 90°V HF horn; efficiency rating of 101dB (1W/1m). It measures 21.88" (55.57cm) high and 19.66" (49.93cm) wide. It carries a manufacturer warranty of 60 months from date of purchase.
