American DJ Ultra Hex Bar 12

The American DJ Ultra Hex Bar 12 is an LED bar from American DJ. Published beam angle: 40 degrees.

5 Dmx channel modes covers 6/7/8/12/36 channels. Power draw is quoted at 90W. Ordering code ULTRAHEXBAR12.

5 DMX Channel Modes	6/7/8/12/36 channels
6 Operational Modes	Auto Run, Program Mode, Sound Active, RGBWA + UV Dimmer, Static Color and DMX-512 Mode
Beam Angle	40 degrees
Refresh Rate	2.88KHz
Electronic Dimming	0-100%
Light output	1680 LUX @ 2M; 478 LUX @4 Meters (40-degree beam)
Power Draw	90W
Linkable	DMX via 3-pin XLR cable; Power via IEC daisy-chain power link (Up to 7 Ultra Hex Bar 12 fixtures)
