AJA KONA IP SMPTE ST 2110 PCIe I/O Card

KONA IP is a PCIe I/O card built for SMPTE ST 2110 (-10, -20, -21, -23, -30, -40), 2022-6 and 2022-7 media transport, with dual SFP+ cages. It supports single-channel ST 2110 for 2K/HD or 4-channel for 4K/UltraHD via ST 2110-23.

An HDMI v1.4b output with 30/36-bit color provides monitoring from 4K down to SD, and the card handles up to 16-channel embedded audio at 24-bit 48 kHz synchronous. It draws 25W typical and 27W maximum in a PCIe form factor.
