Specifications: |
Digital Audio System
- System: Solid State Recorder
- Usable Media: CF memory/Microdrive cards
- Recording and media methods:
- .mp2: MPEG1 Layer II compression
- .mp3: MPEG1 Layer III compression
- .mp3: MPEG2 Layer III compression *for all half sample rates.
- PCM: 16/24 bit linear PCM
- Recording bit rate (selectable):
- MP2 mono: 192, 128, 96, 64, 48, 32 kbps
- MP2 stereo: 384, 256,192,128, 96, 64 kbps
- MP3 mono: 160, 128, 80, 64, 40, 32, 24, 16 kbps
- MP3 stereo: 320, 256, 160,128, 80, 64, 40, 32 kbps
- Sampling frequency:
- Analog:
- 24bit PCM: 96, 88.2, 48, 44.1 kHz
- 16bit PCM: 48, 44.1, 32, 24,22.05, 16, 12, 11.025, 8 khz
- MP2: 48, 44.1, 32 kHz
- MP3: 48, 44.1, 32 , 24, 22.05, 16 kHz
- Digital: 96, 88.2, 48, 44.1 kHz
- Number of channels: 2 (stereo), 1 (mono)
- Frequency response: 44kHz (-0.5dB, fs=96kHz)
- Signal-to-Noise Ratio: IEC-A weighted:
- Total Harmonic Distortion at 0 VU (PCM)
- Dynamic Range: 94dB
Inputs
- MIC IN L/R
- Type: XLR (1:GND, 2:HOT, 3:COLD)
- Input Sensitivity (MIC): 1.2 mVrms/3 kohms
- LINE IN L/R
- Type: RCA jack
- Input Sensitivity: 300 mVrms/22 kohms
- DIGITAL IN
- Type: RCA jack
- Input impedance: 75 ohms
- Standard input level: 0.5 Vp-p
- Sampling frequency: 96, 88.2, 48, 44.1 kHz
- Format: SPDIF (IEC 958 TypeII)
Outputs
- LINE OUT L/R
- Type: RCA jack
- Standard level: 2 Vrms max./2 kohms
- DIGITAL OUT
- Type: RCA jack
- Output impedance: 75 ohms
- Standard output level: 0.5 Vp-p
- Sampling frequency: 96, 88.2, 48, 44.1 kHz
- Format: SPDIF (IEC-958 Type II)
General
- Headphone Output power: 20 mW/32 ohms
- Speaker Output power: 70 mW/4 ohms
- Phantom power: +48V/7mA
- Power consumption:
- Recording/Playback: 6 W
- Charging: 12 W max
- Standby (battery driven): 2.9 mW
- Battery life (Alkaline): 6 hours (typical)
- Dimensions: 10.4" (264 mm) W x 2.0" (55 mm) H x 7.3" (185 mm) D
- Weight: 2 lbs. 14 oz. (1.3 kg)
- Included accessories
- AC adapter
- Battery holder
- Carry strap
- Carry strap retainers x 2
- Screws (ISO 3x10 mm) x 3
- Plastic pin and retainer
- USB cable
- User Guide
- Optional accessories
- Ni-Cd battery pack: RB1100
- Ni-MH battery pack: RB1651
- Carrying cover (vinyl): CLC670
- Mic Remote: RC600
- Attache carrying case: CA200
|
|
