Specifications: |
- System: Solid State Recorder
- Usable Media: CF Memory Card & Microdrive
- Recording Format:
- MP3: MPEG Audio Layer III compression
- PCM: 16 bit linear PCM
- Recording Bit Rate:
- MP3 mono: 64 kbps
- MP3 stereo: 128 kbps
- Sampling Frequency: 44.1, 48 kHz
- Number of Channels : 2 (stereo), 1 (mono)
Audio Performance
- Frequency response : 16,000 Hz (-0.5dB)
- Signal-to-noise ratio:
- LINE 80 dB IEC-A weighted
- MIC 60 dB IEC-A weighted
- Total harmonic distortion at 0 VU (PCM)
- Dynamic range: 80 dB
Inputs
- MIC IN L/R
- Type: XLR (1:GND, 2:HOT, 3:COLD)
- Input sensitivity : 1.2 mV rms /6.5k ohms
- LINE IN L/R
- Type: 1/8" mini jack
- Input sensitivity : 300 mV rms /20k ohms
Outputs
- LINE OUT L/R
- Type: 1/8" mini jack
- Standard level : 2 V rms max. /2k ohms
- Headphone
- Type: 1/8" mini jack
- Output power: 8 mW /32 ohms
- Speaker
- Output power: 150 mW /16 ohms
- Phantom power : +48V, 5mA
General
- Power consumption Recording/Playback: 4 W (DC)
- Battery life (Alkaline) : Hours (typical)
- Dimensions: 4.5" (113 mm) W x 1.9" (47 mm) H x 7.2" (183.5 mm) D
- Weight: 1.1 lbs. (0.5 kg)
- Included Accessories
- CF card (64MB) (US only)
- AC adapter
- USB cable
- Audio cable
- Carry strap
- Screws (ISO 3x10 mm) x 2
- Plastic pin and retainer
- CD-ROM
- User guide
- Optional Accessories:
|
|
