Marshall V-R70P-SD LCD Monitor



Marshall V-R70P-SD G&G Price: $1,185 7" Wide Screen LCD Monitor with SDI Input List Price: $1,499



Accessories:
V-LCD-VA	VESA Adapter for 12" and 15" monitors	$19.95
V-PS12-500	12VDC (500mA) regulated power supply w/coax plug	$16
V-PS12-1000	12VDC (1A) regulated power supply w/coax plug	$24.95
V-PS12-5V-1	12V, 5A Power Supply w/twist lock connector	$89
V-PS6-1.2A	6V Power Supply, 1.2A, w/twist lock connector	$39.95
V-BP12-LCD	Battery attachment for LCD monitor	$75
V-LCD4-PRO-L-HOOD	Hood for V-LCD4-PRO	$21
V-LCD4-ST	Stand for V-LCD4-PA	$39.95
V-LCD-MT-01	1/4" mount LCD to camcorder mount	$24.95
V-LCD4-CASE	Carrying Case for 4" LCD monitor	$40
V-BG-PCB-MS	Color Bar Generator NTSC/PAL Switch	$135
V-BG-P-MS	Color Bar Generator NTSC/PAL black case	$140
V-LCD-CP-001	Control Panel for 6.4" LCD	$99.95
84XXM	BNC-BNC 75ohm RG59 Cable - XXft	$9 (6ft)
94XXM	BNC-BNC HD RG59 Cable - XXft	$10 (6ft)
TCS-5139-XX	4-Pin MiniDin S-Video Cable - XXft	$11 (6ft)
V-PAC-D	Power Adapter Cable (D-type conncetion)	$60
V-PAC-XLR	Power Adapter Cable (4 Pin XLR connection)	$60
RGB-5HD15-X	HD15 to RGB HV Video Cable	$35 (6ft)
V-H700P	Sun Hood for V-R65P-HD & V-R70P	$99.95
V-R65-RPS	Replacement Protection Screen for V-R65P-HD	$69.95
V-R65-1M	Single monitor mount for 19" rack	$129.95
V-R65-2M	Double monitor mount for 19" rack	$99.95
V-CC1	Carrying Case for V-R65P-HD	$180
V-HWP-K	Package of 10 Wipes for LCD displays	$9.95
V-R65-BA	Mount For IDX Batteries	$150
IDX E7S	55 W Lithium Battery	$195
IDX E7	55 W Lithium Battery with Power Link	$279
IDX E10S	82 W Lithium Battery	$339
IDX E10	82 W Lithium Battery with Power Link	$425
IDX VL-2 PLUS	Sequential 2 Channel Charger	$499
IDX VL-4S	Simultaneous 4 Channel Charger	$759

Description:

The V-R70P-SD is the successor to the V-R70-SDI. Significant improvements over the previous model include our Completely Digital TFT-MegapixelT high resolution LCD screen with 1.2 million pixels, V-Mount battery adapter, 4 pin XLR power jack, and optical grade polycarbonate screen protection. Analog signals are digitized using an advanced 10 bit process with 4x over sampling and adaptive 5 line comb filter plus exacting color space conversion. Video is scaled to fit on screen in the highest resolution using a state of the art LSI that incorporates 4x4 pixel interpolation with precision Gamma correction to product the best images available.

Features:

Durable metal enclosure "V" Mount battery adapter included Runs 4 to 6 hours on optional 50WH battery High Resolution 7-inch wide screen 800x480 Dots with 1.2 million pixels Optical grade polycarbonate screen cover with Antireflective/Antiglare coating 100% digital processing Analog signals converted to 10 bit digital High resolution scaling of all images Wide viewing radius - 130° horizontal and 120° vertical provides superior visibility when the viewer is not directly in front of the screen 380 candelas per square meter (cd/m2) luminance produces enhanced image quality in varying light and viewing conditions 400:1 ratio of contrast between black and white luminance values with response rates less than 30 ms results in excellent quality for moving images 4:3 and 16:9 screen aspect ratios Automatic NTSC/PAL format detection Standard inputs: SDI (Smpte-259M) with reshaped & reclocked output Y/C (S-Video) with loop output Composite Video PAL/NTSC with loop output 4 Pin XLR D.C. power jack Easy to see three color tally indicators Built in Color Bars Blue Screen for color adjustment Adjustment Settings Memory Includes ¼-20 mounting plate that can be attached to any edge of the enclosure (additional mounting plates available) Includes universal voltage Class-2 power supply Fits into Tektronix ® WFM7F05/1700F05 rack adapter Optional rack mount kit

Specifications:

Number of Screens: 1 Display (Viewing Area): 7" (6.14"H × 3.27"V) (156.0mm x 83.28mm) Resolution ( RGB Dots): 800H x RGB x 480V (1.2 million pixels) Viewing Angles: 130° H x 120° V Dot Pitch: 0.065 mm (W) x 0.175 (H) Contrast Ratio: 400:1 Pixel Response: <30ms Brightness: 380 cd/m² System: NTSC/PAL auto recognition for standard definition signals (SMPTE RS-170A)
