Image Characteristics
- Brightness - ANSI Lumens 12,000
- Illumination Uniformity 90%
- Size of Color Palette 16.7 Million
- Contrast Ratio - Full ON/OFF 1300:1 (Typical. Lamp control mode "Auto")
- Horizontal Resolution - TV Lines 800 (HDTV)
- Imaging System 1.8" Polysilicon active matrix TFT Panels x3
- Scanning Frequency Auto: H Sync. 15-120kHz; V Sync. 50-120Hz
- Screen Pixels 1024 x 768 in stripe configuration
- Total Pixels 2,359,296 ((1024 x 768) x 3)
Lamp
- Estimated Lamp Life Hours Up to 2,000 hrs. in Standard
- Lamp 300 Watt UHP x 4
Image Control
- Vertical Keystone Correction - Digital Digital: Variable Adjustment +30°~ -30°
- Vertical Anti-Keystone Power Lens Shift, Ratio (max.) (T:B) 10:0 ~ 0:10
- Lateral Anti-Keystone Power Lens Shift , Ratio (L:R) 3:2~2:3
- Front Elevation up to 5.7° up
- Maximum Pitch up to 5.7° up
- Image Orientation Normal, Reversed, Inverted
Supplied Lens
- Lens Type Not Included - See Lens Chart
- Image Diagonal - Max. 600 in
- Image Diagonal - Min. 40 in
- Image Width - Max. 40 ft.
- Image Width - Min. 2.67 ft.
- Throw Distance - Max. See specifications for selected lens
- Throw Distance - Min. See specifications for selected lens
Controls
- Local Control Full Function
- Remote Control - Projector & Mouse Wireless / wired x 1
Computer Specifications
- Computer Dot Clock 230MHz
- Computer Native Resolution 1024 x 768
- Computer Compatiblity UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA & MAC
- Computer Image Sizing Normal or Smart compressed or expanded
Video Specifications
- Video Input Systems Composite/Component: Y,Pb/Cb,Pr/Cr, S-Video
- Video Color Systems NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
- SDTV Compatibility 480i/p, 575i/p
- HDTV Compatibility 720p, 1035i, 1080i
- Video Formats Supported 4:3 & 16:9
- Video Image Sizing Progressive Video Scaling
Connections
- Number of Channels 4
- Number of Modules 4
- Modules Interchangeable: standard configuration below.
- Input Module 1a: DVI: DVI-I x 1 data/video, RCA x 2 audio, 8-pin DIN x 1 control
- Input Module 1b: (provides DVI digital data, HD15 analog data via adapter and DVI w/HDCP digital video)
- Input Module 2a: RGB/DVD/HD BNC x 5 video, RCA x 2 audio, 8-pin DIN x 1 control
- Input Module 2b: (RGB G-sync, RGB H+V, RGBHV, Component and Y, Pb/Cb, Pr/Cr)
- Input Module 3a: Y/C BNC x 2 & S-Video x 1 video, RCA x 2 audio
- Input Module 4a: PC HD15 x 1 data, RCA x 2 audio, 8-pin DIN x 1 control
- Output Audio: Output - Line (Stereo) RCA x 2 (L & R)
- MiniStereo x 1 Wired Remote Control
- Port Mouse Control Ports (On input modules 1, 2 & 4) Mini DIN x 3 USB x 1
- Port RS-232 Control Port Dsub9 x 2 (In & Out)
Physical Specifications
- Cabinet Height 9.9 in.
- Cabinet Width 22.9 in.
- Cabinet Depth 30.8 in.
- Packaged Height 26.1 in.
- Packaged Width 34.7 in.
- Packaged Depth 48.4"
- Weight 80.5 lbs.
- Packaged Weight 109.1 lbs.
Electrical Specifications
- Power Management Auto Lamp Shut-Off
- Power Requirements 100 ~ 120/200 ~ 240V AC 50/60Hz (Japan 200V)
- Power Requirement note In North America requires a 20 am dedicated circuit. (NEMA 5-20p)
- Power Consumption 1800 Watts
- Power Cord 10' Type 3, Detachable
Environment
- Operating Noise - dBA 51.0000000000
- Operating Temperature - Max. 95 °F
- Operating Temperature - Min. 41 °F
- Generated Heat 6142 BTU/hr (1548 Kcal/hr)
Eco-Mode Specifications
- Brightness (ECO Mode) - ANSI Lumens 10,000
- Estimated Lamp Life Hours (ECO Mode) 2,500
Safety
- Compliance UL, UL Canada, CE
User Maintenance
- User maintenance Clean Air Filter, Replace Lamp
Warranty
- Warranty - Unit (to original end-use customer) 3 Yr. / 6000 hr. use* (Parts/Labor to Correct Defects)* Whichever Occurs First
- Warranty - Lamp (to original end-use customer) 90 Days/500 hr. use * (Pro-Rata Replacement of Failed Lamp) * Whichever Occurs First
|
