Image Characteristics
- Brightness - ANSI Lumens 3,800
- Size of Color Palette 16.7 Million
- Contrast Ratio - Full ON/OFF 1000:1
- Illumination Uniformity 90%+
- Imaging System 1.0 PolySilicon active matrix TFT Panels x 3
- Scanning Frequency Auto: H Sync. 15-100 kHz; V Sync. 50-100 Hz
- Screen Pixels 1024 x 768 in stripe configuration
- Total Pixels 2,359,296 (1024 x 768) x 3
Lamp
- Lamp 300 Watt UHP
Image Control
- Vertical Keystone Correction - Digital Up to 40 degrees Up or Down
- Horizontal Anti Keystone Power Lens Shift, Left or Right 15%
- Vertical Anti-Keystone Power Lens Shift, Up only 50%
- Maximum Pitch anywhere up to 360 degrees off the horizontal axis
Lens
- Lens Type Power Zoom & Focus
- Image Diagonal - Max. 300"
- Image Diagonal - Min. 30"
- Image Width - Max. 20 ft.
- Image Width - Min. 2.0 ft.
- Throw Distance - Max. 32.8 ft.
- Throw Distance - Min. 3.9 ft.
- Throw:Width ratio 1.64 ~ 2.13:1
- Zoom Ratio - Max:Min: 1.3:1
Controls
- Local Control Full Function
- Remote Control - Projector & Mouse Wireless (Infra Red)/Wired with Laser Pointer x 1
Computer Specifications
- Computer Native Resolution 1024 x 768
- Computer Compatiblity UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA & MAC
- Computer Formats Supported 1600x1200 through 640x480
- Computer Dot Clock 140 MHz
- Computer Image Sizing Normal or Smart compressed or expanded
Video Specifications
- Video Input Systems Analog: Composite, S-Video, Component & Digital: DVI w/HDCP
- Video: Compatibility 480i/p, 575i/p, 720p, 1035i, 1080i-50/60
- Video Color Systems NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
- Video Formats Supported 4:3 & 16:9
Audio Specifications
- Amplifier Mono: 1 Watts RMS
- Speakers (Built-in) 1 x 1.1"
Connections
- On Input 1 - DVI-D Computer: Digita / Video: Digital with HDCP
- On Input 1 - HD15 x 1 Computer: Analog
- On Input 1 - ministereo x 1 Stereo Audio: MiniStereo x 1
- On Input 2 - 3 BNC Video: Analog (Y,Pb/Cb,Pr/Cr)
- On Input 2 - 5 BNC Computer: Analog (RGBHV)
- On Input 2 - ministereo x 1 Stereo Audio: MiniStereo x 1
- 4 pin DIN (S-Video) x 1 S-Video Input (Y/C)
- MiniStereo x 1 Wired Remote Control
- MiniStereo x 1 #2 Audio Line Out (Variable)
- 8 pin DIN x 1 RS-232 control port
- RCA x 1 (yellow) Video In (Composite)
- RCA x 2 (L & R or red & white) Audio In - Video (Composite/S-video)
Physical Specifications
- Cabinet Height 6.46"
- Cabinet Width 13.7"
- Cabinet Depth 17.48"
- Packaged Height 14.6"
- Packaged Width 19.3"
- Packaged Depth 23.3"
- Weight 19.2 lbs.
- Packaged Weight 28.0 lbs.
Electrical Specifications
- Power Management Auto Shut-Off
- Power Requirements 100-240V AC, 50/60Hz
- Power Consumption 430 Watts
- Power Cord 10' (3M) Type 3, Detachable
Environment
- Operating Temperature - Max. 95° F
- Operating Temperature - Min. 41° F
- Generated Heat 1467 BTU (370 KC)
Eco-Mode Specifications
- Estimated Lamp Life Hours (ECO Mode) 3,000
- Operating Noise (ECO Mode) - dBA 31
- Power Consumption (ECO Mode) - Watts 360
- Generated Heat (ECO Mode) 1228 BTU (310 KC)
Security
- Kensington Security Slot Cable Locking System
- Keylock Function Local or Remote
User Maintenance
- User maintenance Clean Air Filter, Replace Lamp
Warranty
- Warranty - Unit (to original end-use customer) 3 Yr. / 6000 hr. use* (Parts/Labor to Correct Defects)* Whichever Occurs First
- Warranty - Lamp (to original end-use customer) 90 Days/500 hr. use * (Pro-Rata Replacement of Failed Lamp) * Whichever Occurs First
Warning
- Laser Warning The following warning is required by the US FDA and pertains to the laser pointer in wireless remote control for this projector. Caution! Laser Radiation - Do not stare into beam.
- Mercury Warning Lamp contains Mercury. Do not put in trash. Dispose of as Hazardous Waste, according to Local, State or Federal Laws.
|
