Image Characteristics
- Brightness - ANSI Lumens 2,500
- Size of Color Palette 16.7 Million
- Illumination Uniformity 80%
- Imaging System 0.63" Polysilicon TFT active matrix type panels x3
- Scanning Frequency Auto: H Sync. 15-100 KHz; V Sync. 50-100 Hz
- Screen Pixels 1024 x 768
- Total Pixels 2,359,296 ((1024 x 768) x 3)
Lamp
- Estimated Lamp Life Hours 2000
- Lamp 200 Watt UHP
- Lamp House Cover True
Image Control
- Front Elevation up to 10° up
- Image Orientation Normal, Reversed, Inverted
Lens
- Lens Type Manual Zoom & Focus
- Image Diagonal - Max. 300 in.
- Image Diagonal - Min. 40 in.
- Image Width - Max. 20'
- Image Width - Min. 2.67'
- Throw Distance - Max. 38.7 ft.
- Throw Distance - Min. 3.3 ft.
- Throw:Width ratio 1.24~1.93:1
Controls
- Local Control Full Function
- Remote Control - Projector Wireless (Infra Red) with Laser Pointer x 1
Computer Specifications
- Computer Native Resolution 1024 x 768
- Computer Higher Resolution Displayed panned or Smart Compressed
- Computer Lower Resolution Displayed normal or Smart Expanded
- Computer Compatiblity UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA & MAC
- Computer Dot Clock 140 MHz
Video Specifications
- Video Input Systems Analog: Composite, S-Video, Component Digital: DVI w/HDCP
- Video Color Systems NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
- SDTV Compatibility 480i/p, 575i/p
- HDTV Compatibility 720p, 1035i, 1080i
- Video Formats Supported 4:3 & 16:9
- Video Image Sizing Video Scaling Technology
Audio Specifications
- Amplifier Monaural, 1 Watt RMS (T.H.D. 10%)
- Speakers (Built-in) 1 x 1.1
Connections
- On Input 1 - DVI-I x 1 Computer 1 - Digital or, Computer 1 - Analog (via HD15 ~ DVI-I cable adapter)
- On Input 1 - ministereo x 1 Audio In (Computer 1) - Stereo
- On Input 2 - HD15 x 1 Computer Input - Analog or, Component Video In (via adapter)
- USB (series B) x 1 Mouse control port
- 4 pin DIN (S-Video) x 1 S-Video Input (Y/C)
- MiniStereo x 1 #2 Audio Line Out (Variable)
- 8 pin DIN x 1 RS-232 control & Service Port
- RCA x 1 (yellow) Video In (Composite)
- RCA x 2 (L & R or red & white) Audio In - Video
Physical Specifications
- Cabinet Height 2.28 in.
- Cabinet Width 9.66 in.
- Cabinet Depth 6.82 in.
- Packaged Height 13.2 in.
- Packaged Width 16.2 in.
- Packaged Depth 14.2 in.
- Weight 5.7 lbs.
- Packaged Weight 14.1 lbs.
Electrical Specifications
- Power Requirements 100 ~ 120/200 ~ 240 V AC 50/60Hz
Environment
- Operating Noise - dBA 35.7
- Operating Temperature - Max. 95° F
- Operating Temperature - Min. 41° F
Eco-Mode Specifications
- Brightness (ECO Mode) - ANSI Lumens 2,000
- Estimated Lamp Life Hours (ECO Mode) 2,000
- Operating Noise (ECO Mode) - dBA 30
- Power Consumption (ECO Mode) - Watts 210
Safety
- Compliance UL, UL Canada, CE
Security
Kensington Security Slot Cable Locking System
User Maintenance
- User maintenance Clean Air Filter, Replace Lamp
Warranty
- Warranty - Unit (to original end-use customer) 3 Yr. / 6000 Hr.* (Parts/Labor to Correct Defects) * Whichever Occurs First
- Warranty - Lamp (to original end-use customer) 90 Days (Failed Lamp Replaced Pro-Rata)
Warning
- Laser Warning The following warning is required by the US FDA and pertains to the laser pointer in wireless remote control for this projector. Caution! Laser Radiation - Do not stare into beam.
- Mercury Warning Lamp contains Mercury. Do not put in trash. Dispose of as Hazardous Waste, according to Local, State or Federal Laws.
|
