Image Characteristics
- Brightness - ANSI Lumens 2,000
- Size of Color Palette 16.7 Million
- Contrast Ratio - Full ON/OFF 400:1
- Illumination Uniformity 85%+
- Imaging System 0.6" PolySilicon actice matrix TFT Panels x 3
- Scanning Frequency Auto H Sync. 15-100kHz; V Sync. 50-100Hz
- Screen Pixels 1024 x 768 in stripe configuration
- Total Pixels 2,359,296
Lamp
- Estimated Lamp Life Hours 2000
- Lamp 200 Watt UHP
Image Control
- Vertical Keystone Correction - Digital Digital: up to 20° up or down
- Anti-Keystone Fixed Image Offset, Ratio (Top:Bottom) 6:1
- Front Elevation up to 10° up /+/-10°
- Image Orientation Normal, Reversed, Inverted
Lens
- Lens Speed 1.7
- Focal Length - Min. 0.79 in.
- Lens Type Manual Focus
- Image Diagonal - Max. 300 in.
- Image Diagonal - Min. 40 in.
- Image Width - Max. 20 ft.
- Image Width - Min. 2.67 ft.
- Throw Distance - Max. 42.38 ft.
- Throw Distance - Min. 4.27 ft.
- Throw:Width ratio 1.62:1
- Zoom (x) 4
Controls
- Local Control Full Function
- Remote Control - Projector Wireless (Infra Red) x 1
Computer Specifications
- Computer Native Resolution 1024 x 768
- Computer Higher Resolution Displayed panned or Smart Compressed
- Computer Lower Resolution Displayed normal or Smart Expanded
- Computer Compatiblity UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA & MAC
- Computer Formats Supported 1600x1200 through 640x480
- Computer Dot Clock 140 MHz
Video Specifications
- Video Input Systems Composite/Component: Y,Pb/Cb,Pr/Cr, S-Video
- Video Color Systems NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
- SDTV Compatibility 480i/p, 575i/p
- HDTV Compatibility 720p, 1035i, 1080i
- Video Formats Supported 4:3 & 16:9
- Video Image Sizing Video Scaling Technology
Audio Specifications
- Amplifier Mono: 1 Watts RMS
- Speakers (Built-in) 1 x 1.1"
Connections
- On Computer Out - HD15 x 1 Monitor Out
- HD15 x 1 Computer - Component / S-Video (with optional adapters)
- MiniStereo x 1 Audio In (Computer) - Stereo Audio In (Component) - Stereo
- MiniStereo x 1 #2 Audio Line Out (Variable)
- 8 pin DIN x 1 Service Port (for RS-232 control)
- RCA x 1 (yellow) Video In (Composite)
- RCA x 2 (L & R or red & white) Audio In - Video
Physical Specifications
- Cabinet Height 3.15 in.
- Cabinet Width 13.00 in.
- Cabinet Depth 9.33 in.
- Packaged Height 8.9 in.
- Packaged Width 17.1 in.
- Packaged Depth 18.1 in.
- Weight 6.4 lbs.
- Packaged Weight 10.8 lbs.
Electrical Specifications
- Power Management Auto Shut-Off
- Power Requirements 100 ~ 120/200 ~ 240V AC 50/60Hz
- Power Consumption 250 Watts
- Power Cord 10' (3M) Type 3, Detachable
Environment
- Operating Noise - dBA 30.00
- Operating Temperature - Max. 95° F
- Operating Temperature - Min. 41° F
- Generated Heat 853 BTU/hr (215 BTU/hr)
Eco-Mode Specifications
- Brightness (ECO Mode) - ANSI Lumens 1,600
- Estimated Lamp Life Hours (ECO Mode) 3,000
- Operating Noise (ECO Mode) - dBA 25
- Power Consumption (ECO Mode) - Watts 205
- Generated Heat (ECO Mode) 700 BTU/hr (176 KC/hr)
Safety
- Compliance UL, cUL, CE
Security
Kensington Security Slot Cable Locking System
User Maintenance
- User maintenance Clean Air Filter, Replace Lamp
Warranty
- Warranty - Unit (to original end-use customer) 3 Yr. / 6000 hr. use* (Parts/Labor to Correct Defects)* Whichever Occurs First
- Warranty - Lamp (to original end-use customer) 90 Days (Failed Lamp Replaced Pro-Rata)
Warning
- Mercury Warning Lamp contains Mercury. Do not put in trash. Dispose of as Hazardous Waste, according to Local, State or Federal Laws.
|
