Image Characteristics
- Brightness 5500 ANSI Lumens
- Illumination Uniformity 90%+
- Size of Color Palette 16.7 Million
- Contrast Ratio - Full ON/OFF 1000:1
- Horizontal Resolution - TV Lines 800
- Imaging System 1.3" PolySilicon active matrix TFT Panels x 3
- Scanning Frequency Auto: H Sync. 15-100 kHz; V Sync. 48-100 Hz
- Screen Pixels 1024 x 768
- Total Pixels 2,359,296 ((1024 x 768) x 3)
Lamp
- Estimated Lamp Life Hours up to 1500
- Lamp 318 Watt UHP
Image Control
- Horizontal Keystone Correction - Digital Digital: up to 15° left or right
- Vertical Keystone Correction - Digital Digital: up to 35°up or down
- Anti-Keystone Power Lens Shift, Ratio (Top:Bottom) 10:0~1:1
- Front Elevation up to 10.5° up
- Image Orientation Normal, Reversed, Inverted
Supplied Lens
- Lens Speed f:1.8~2.1
- Focal Length - Max. 2.473"
- Lens Protection Lens Cap
- Focal Length - Min. 1.905"
- Lens Type Power Zoom & Focus
- Image Diagonal - Max. 400"
- Image Diagonal - Min. 31"
- Image Width - Max. 26.7'
- Image Width - Min. 2.07'
- Throw Distance - Max. 48.2'
- Throw Distance - Min. 4.6'
- Throw:Width ratio 1.82 ~ 2.37:1
- Zoom Ratio - Max:Min: 1.3:1
- Zoom (x) 49x digital zoom
Controls
- Local Control Full Function
- Remote Control - Projector & Mouse Wireless (Infra Red)/Wired with Laser Pointer x 1
Computer Specifications
- Computer Dot Clock 180 MHz
- Computer Native Resolution 1024 x 768
- Computer Compatiblity UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA & MAC
- Computer Formats Supported 1600x1200 through 640x480
- Computer Image Sizing Normal or Smart compressed or expanded
Video Specifications
- Video Input Systems Composite/Component: Y,Pb/Cb,Pr/Cr, S-Video
- Video Color Systems NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
- SDTV Compatibility 480i/p, 575i/p
- HDTV Compatibility 720p, 1035i, 1080i, -50/60
- Video Formats Supported 4:3 & 16:9
- Video Image Sizing Video Scaling Technology
Audio Specifications
- Amplifier Stereo: 3 Watts RMS Internal; 5 Watts RMS External
- Speakers (Built-in) Stereo: 2 x 3.5 in.
Connections
- Input 1a. either Computer: HD15 x 1 RGB
- Input 1b. or DVI-D x 1 Digital Computer or Video Input w/ HDCP
- Input 1c. plus Audio: Stereo: MiniStereo x 1 (L & R)
- Input 2a. either Computer: BNC x 5 (RGBHV)
- Input 2b. or Video: BNC x 3 (Composite/Component: Y,Pb/Cb,Pr/Cr)
- Input 2c. plus, Audio: Stereo: MiniStereo x 1 (L & R)
- Input 3a. Video: RCA x 3 (Composite/Component:Y,Pb/Cb,Pr/Cr) S-Video x1
- Input 3b. Audio: RCA x 2 (L & R Stereo)
- Output Computer: Monitor - HD15 x 1 on Input 1 (switchable)
- Output Computer: Audio Line - Stereo: MiniStereo x 1 (L & R) (switchable)
- Output Audio: External Speaker - 5W x2 (Stereo) Push Terminal x 2 (front)
- Port Mouse: USB-Bx1
- Port Control: 8-pinDINx1
- Port Wired RC: MiniStereox1
Physical Specifications
- Cabinet Height 6.6"
- Cabinet Width 12.6"
- Cabinet Depth 16.8"
- Packaged Height 12.0"
- Packaged Width 17.1"
- Packaged Depth 24.2"
- Weight 19.8 lbs.
- Packaged Weight 28 lbs.
Electrical Specifications
- Power Management Auto Shut-Off
- Power Requirements 100-240V AC, 50/60Hz
- Power Consumption 480 Watts
- Power Cord 10' (3M) Type 3, Detachable
Environment
- Operating Noise - dBA 42.0000000000
- Operating Temperature - Max. 95F
- Operating Temperature - Min. 41F
- Generated Heat 1638 BTU/hr (413 Kcal/hr)
Eco-Mode Specifications
- Brightness (ECO Mode) - ANSI Lumens 4,200
- Estimated Lamp Life Hours (ECO Mode) 2,500
- Operating Noise (ECO Mode) - dBA 36
- Power Consumption (ECO Mode) - Watts 370
- Generated Heat (ECO Mode) 1263 (318) in Eco Mode
Safety
- Compliance UL, UL Canada, CE
Security
- Kensington® Security Slot Cable Locking System
User Maintenance
- User maintenance Clean Air Filter, Replace Lamp
Warranty
- Warranty - Unit (to original end-use customer) 3 Yr. / 6000 hr. use* (Parts/Labor to Correct Defects)* Whichever Occurs First
- Warranty - Lamp (to original end-use customer) 90 Days/500 hr. use * (Pro-Rata Replacement of Failed Lamp) * Whichever Occurs First
Warning
- Laser Warning CAUTION! The following warning is required by the US FDA and pertains to the laser pointer in the wireless remote control for this projector. Laser Radiation: Do not stare into beam. Max. Output: 1 mW. Wave Length: 650 +/
- Mercury Warning Lamp contains Mercury. Do not put in trash. Dispose of as Hazardous Waste, according to Local, State or Federal Laws.
|
