Image Characteristics
- Brightness - ANSI Lumens 3,000
- Illumination Uniformity 90%+
- Size of Color Palette 16.7 Million
- Contrast Ratio - Full ON/OFF 1000:1
- Horizontal Resolution - TV Lines 800 (HDTV)
- Imaging System 1.21" Polysilicon active matrix TFT Panels x 3
- Screen Pixels 1366 x 768
- Total Pixels 3,147,264 ((1366 x 768)x 3)
Lamp
- Estimated Lamp Life Hours 1500
- Lamp 300 Watt NSH
Image Control
- Horizontal Keystone Correction - Digital ±20°
- Vertical Keystone Correction - Digital ±30°
- Front Elevation up to 10.5° up
- Image Orientation Normal, Reversed, Inverted
Supplied Lens
- Lens Speed f:1.8~2.1
- Focal Length - Max. 2.47 in.(62.8 mm)
- Focal Length - Min. 1.9 in.(48.4 mm)
- Lens Type Power Zoom & Focus
- Image Diagonal - Max. 400 in.
- Image Diagonal - Min. 30 in.
- Image Width - Max. 29.1'
- Image Width - Min. 2.2'
- Throw Distance - Max. 52.2'
- Throw Distance - Min. 5.0'
- Throw:Width ratio 1.81 ~ 2.36:1
- Zoom Ratio - Max:Min: 1.3:1
Controls
- Local Control Full Function
- Remote Control - Projector & Mouse RF Wireless / wired x 1
Computer Specifications
- Computer Dot Clock 180 MHz
- Computer Native Resolution 1366 x 768
- Computer Compatiblity UXGA, SXGA+, SXGA, WXGA, XGA, SVGA, VGA & MAC
- Computer Formats Supported 1600x1200, 1280x1024, 1024x768, 800x600, 640x480
- Computer Image Sizing Normal or Smart compressed or expanded
Video Specifications
- Video Input Systems Analog: Composite, S-Video, Component Digital: DVI w/HDCP
- Video Color Systems NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
- SDTV Compatibility 480i/p, 575i/p
- HDTV Compatibility 720p, 1035i, 1080i, -50/60
- Video Formats Supported 4:3 & 16:9
- Video Image Sizing Video Scaling Technology
Audio Specifications
- Amplifier Stereo: 2 Watts RMS
- Speakers (Built-in) Stereo (2 in.) x 2
Connections
- On Computer In 1 - HD15 x 1 Computer In - Analog Input
- DVI-D Computer Input - Digital RGB or HDCP
- MiniStereo x 1 Audio In (Computer 1) - Stereo
- MiniStereo x 1 #2 Audio In (Video) - Stereo
- 5 BNC Computer 2 Input - Analog (RGBHV) or, Video - (3BNC) (Composite/Component: Video/Y, Pb/Cb, Pr/Cr)
- 4 pin DIN (S-Video) x 1 S-Video Input (Y/C)
- RCA x 2 (L & R or red & white) Audio In - Video (S-Video, Component (Y,Pb/Cb,Pr/Cr))
Physical Specifications
- Cabinet Height 6.6 in. (168 mm.)
- Cabinet Width 12.6 in. (168 mm.)
- Cabinet Depth 16.9 in. (168 mm.)
- Weight 19.2 lbs.
- Packaged Weight 27.6 lbs. (12.5 kg.)
Electrical Specifications
- Power Management Auto Shut-Off
- Power Requirements 100-240V AC, 50/60Hz
- Power Consumption 450 Watts
- Power Cord 10' (3M) Type 3, Detachable
Environment
- Operating Noise - dBA 33.0000000000
- Operating Temperature - Max. 95F (35C)
- Operating Temperature - Min. 41F (5C)
- Generated Heat 1536 BTU/hr (387 Kcal/hr)
Safety
- Compliance UL, UL Canada, CE
Security
- Kensington® Security Slot Cable Locking System
User Maintenance
- User maintenance Clean Air Filter, Replace Lamp
Warranty
- Warranty - Unit (to original end-use customer) 3 Yr. / 6000 Hr.* (Parts/Labor to Correct Defects)* Whichever Occurs First
- Warranty - Lamp (to original end-use customer) 90 Days (Failed Lamp Replaced Pro-Rata)
Warning
- Mercury Warning Lamp contains Mercury. Do not put in trash. Dispose of as Hazardous Waste, according to Local, State or Federal Laws.
|
