Image Characteristics
- Brightness - ANSI Lumens 2500
- Illumination Uniformity 85%
- Size of Color Palette 16.7 Million
- Contrast Ratio - Full ON/OFF 2000:1
- Imaging System 0.544 in. DDR XGA DMD™
- Scanning Frequency Auto: H Sync. 15-70kHz; V Sync. 45-85Hz
- Screen Pixels 1024 x 768
- Total Pixels 786,432
Supplied Lens
- Lens Speed f: 2.4~2.6
- Focal Length - Max. 21.9 mm
- Lens Protection Lens Cap
- Focal Length - Min. 19 mm
- Lens Type Manual Zoom & Focus
- Image Diagonal - Max. 300"
- Image Diagonal - Min. 40"
- Image Width - Max. 20'
- Image Width - Min. 2.67'
- Throw Distance - Max. 39.8'
- Throw Distance - Min. 4.6'
- Throw:Width ratio 1.72~1.99:1
- Zoom Ratio - Max:Min: 1.15:1
Controls
- Local Control Full Function
- Remote Control - Projector Wireless (Infra Red) x 1
Computer Specifications
- Computer Dot Clock 12~108 MHz
- Computer Native Resolution 1024 x 768
- Computer Compatiblity SXGA, XGA, SVGA, VGA & MAC
- Computer Formats Supported 1280x1024, 1024x768, 800x600, 640x480
- Computer Higher Resolution Displayed panned or Smart Compressed
- Computer Lower Resolution Displayed normal or Smart Expanded
Video Specifications
- Video Input Systems Composite/Component: Y,Pb/Cb,Pr/Cr, S-Video
- Video Color Systems NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
- Video Formats Supported 4:3 & 16:9
- Video Image Sizing Video Scaling Technology
Audio Specifications
- Amplifier Mono: 2 Watts
- Speakers (Built-in) 1.6 x 1.1in. (4 x 2.85cm) oval x 1
Connections
- On Input 3 - 4 pin DIN (S-Video) x 1 S-Video Input (Y/C)
- DB9 RS-232 Control Port
- HD15 x 1 Computer / Component Video (via supplied cable)
- HD15 x 1 (#2) Computer / Component Video (via supplied cable)
- MiniStereo x 1 Audio In (Computer 1 & 2) - Stereo
- RCA x 1 (yellow) Video In (Composite)
- RCA x 2 (L & R or red & white) Audio In - Video
Physical Specifications
- Cabinet Height 4.3"
- Cabinet Width 12.4"
- Cabinet Depth 11.6"
- Weight 8.6 lbs
Electrical Specifications
- Power Management Auto Shut-Off
- Power Requirements 100-240V AC, 50/60Hz
- Power Consumption 350 Watts
- Power Cord 6' (2M) Type 3, Detachable
Environment
- Operating Noise - dBA 37
- Operating Temperature - Max. 95 F
- Operating Temperature - Min. 41 F
- Generated Heat 922 BTU/hr (233 Kcal/hr)
Eco-Mode Specifications
- Estimated Lamp Life Hours (ECO Mode) 3000
- Operating Noise (ECO Mode) - dBA 35
- Power Consumption (ECO Mode) - Watts 196
- Generated Heat (ECO Mode) 669 BTU/hr (169 Kcal/hr)
Safety
- Compliance UL, UL Canada, CE
Security
- Kensington® Security Slot Cable Locking System
User Maintenance
- User maintenance Clean Air Filter, Replace Lamp
Warranty
- Warranty - Unit (to original end-use customer) 3 Yr. / 6000 Hr.* (Parts/Labor to Correct Defects) * Whichever Occurs First
- Warranty - Lamp (to original end-use customer) 90 Days (Replacement of Failed Lamp)
Warning
- Mercury Warning Lamp contains Mercury. Do not put in trash. Dispose of as Hazardous Waste, according to Local, State or Federal Laws.
|
