Image Characteristics
- Brightness - ANSI Lumens 1,200
- Illumination Uniformity 85%
- Size of Color Palette 16.7 Million
- Contrast Ratio - Full ON/OFF 6500:1
- Horizontal Resolution - TV Lines 720 (DTV 720p)
- Imaging System 0.65 DMD™
- Scanning Frequency Auto: H Sync. 15-70kHz; V Sync. 45-85Hz
- Screen Pixels 1280 x 768
- Total Pixels 983,040
Lamp
- Estimated Lamp Life Hours 2000
- Lamp 275W SHP
Image Control
- Anti-Keystone (16:9) Fixed Image Offset, 114.3% of Image Height, up
- Front Elevaton / Maximum Tilt (16:9) up to 8° up
- Image Shift (16:9) up to 3.3% of image height Up or Down
- Keystone Correction - Digital Digital: up to 13° U/D or L/R or Geometric
- Color Wheel 6-Segment, 5X speed color wheel
- Image Orientation Normal, Reversed, Inverted
Supplied Lens
- Image Diagonal - Max. (16:9) 300"
- Image Diagonal - Min. (16:9) 40"
- Image Width - Max. (16:9) 21.75'
- Image Width - Min. (16:9) 2.92'
- Throw Distance - Max. (16:9) 34.42'
- Throw Distance - Min. (16:9) 4.0'
- Throw:Width ratio (16:9) 1.37~1.58:1 (+/- 3.5%)
- Lens Speed f:2.4~2.6
- Focal Length - Max. 21.9 mm
- Lens Protection Lens Cap
- Focal Length - Min. 19.0 mm
- Lens Type Manual Zoom & Focus
- Zoom Ratio - Max:Min: 1.15:1
Controls
- Local Control Full Function
- Remote Control - Projector Wireless (Infra Red) x 1
Computer Specifications
- Computer Aspect Ratio 4:3 and 16:9
- Computer Dot Clock 85 MHz
- Computer Native Resolution WXGA / 1280 x 768
- Computer Compatiblity WXGA, XGA, SVGA, VGA & MAC
- Computer Formats Supported 1280 x 768, through 640x480
- Computer Image Sizing (SVGA and VGA) Smart Expanded
Video Specifications
- Video Input Systems Analog: Composite, S-Video, Component; Digital: HDMI (w/HDCP)
- Video: Compatibility NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N & 60
- SDTV Compatibility 480i/p(60), 540p(60), 576i/p(50)
- HDTV Compatibility 720p(60), 1035i(50/60), 1080i(50/60)
- Video Formats Supported 4:3 & 16:9
- Video Image Sizing Video Scaling Technology
- Video Native Resolution 720p
Connections
- On Input 2 - RCA x 3 Video: Analog: Component Y/Pb/Pr (Y/Cb/Cr)
- On Input 5 - HD15 x 1 Either Computer Analog or Component Video (using optional adapter cable)
- On Input 6 - HDMI x 1 Video: DTV & HDTV (w/HDCP)
- Trigger Terminal DC 12V output
- On Input 1 - RCA x 3 Video: Analog: Component Y/Pb/Pr (Y/Cb/Cr)
- On Input 3 - 4 pin DIN (S-Video) x 1 S-Video Input (Y/C)
- On Input 4 - RCA x 1 Video: Composite
- 9 pin DIN x 1 RS-232 Control Port
Physical Specifications
- Cabinet Height 4.7"
- Cabinet Width 12.4"
- Cabinet Depth 11.0"
- Height (including Protrusions) 4.8"
- Depth (including Protrusions) 11.6"
- Width (including Protrusions) 12.4"
- Packaged Height 10.7"
- Packaged Width 17.4"
- Packaged Depth 18.1"
- Weight 8.8 lbs.
- Packaged Weight 16.5 lbs.
Electrical Specifications
- Power Management Auto Shut-Off
- Power Requirements 100-240V AC, 50/60Hz
- Power Consumption 355 Watts
- Power Cord 5.9' (1.8M) Type 3, Detachable
Environment
- Operating Noise - dBA 33
- Operating Temperature - Max. 95 °F
- Operating Temperature - Min. 41 °F
- Generated Heat 1212 BTU/hr. (306 Kcal/hr.)
Eco-Mode Specifications
- Brightness (ECO Mode) - ANSI Lumens 960
- Estimated Lamp Life Hours (ECO Mode) 3,000
- Operating Noise (ECO Mode) - dBA 30
- Power Consumption (ECO Mode) - Watts 310
- Generated Heat (ECO Mode) 1058 BTU/hr. (267 Kcal/hr)
Safety
- Broadcast Compliance FCC Rules, Part 15: Class B
- Compliance UL, cUL, CE
Security
- Kensington® Security Slot Cable Locking System
- UPC 4571194670516
User Maintenance
- User maintenance Replace Lamp
Warranty
- Warranty - Unit (to original end-use customer) 3 Yr. / 6000 hr. use* (Parts/Labor to Correct Defects)* Whichever Occurs First
- Warranty - Lamp (to original end-use customer) 90 Days (Failed Lamp Replaced Pro-Rata)
Warning
- Mercury Warning Lamp contains Mercury. Do not put in trash. Dispose of as Hazardous Waste, according to Local, State or Federal Laws.
|
