Image Characteristics
- Brightness - ANSI Lumens 1,200
- Illumination Uniformity 85%
- Size of Color Palette 16.7 Million
- Contrast Ratio - Full ON/OFF 2500:1
- Horizontal Resolution - TV Lines 720 (DTV 720p)
- Imaging System 0.8 in. HD2+ DMD™
- Scanning Frequency Auto: H Sync. 15-70kHz; V Sync. 43-75Hz
- Screen Pixels 1280 x 720
- Total Pixels 921,600
Lamp
- Estimated Lamp Life Hours 2000
- Lamp 275W SHP
Image Control
- Horizontal Keystone Correction - Digital ±13°
- Vertical Keystone Correction - Digital ±18°
- Anti-Keystone Fixed lens shift 104.5% up
- Color Wheel 6 segment, 3X speed
Supplied Lens
- Lens Speed f:2.0~2.5
- Focal Length - Max. 31.6 mm
- Lens Protection Lens Cap
- Focal Length - Min. 21.3 mm
- Lens Type Power Zoom & Focus
- Iris Auto - Adjustable manually
- Image Diagonal - Max. 200"
- Image Diagonal - Min. 40"
- Image Width - Max. 13.3'
- Image Width - Min. 2.67'
- Throw Distance - Max. 25.8'
- Throw Distance - Min. 3.5'
- Throw:Width ratio 1.5~2.2:1
- Zoom Ratio - Max:Min: 1.5:1
Controls
- Remote Control - Projector Wireless (Infra Red) x 1
Computer Specifications
- Computer Dot Clock 80 MHz
- Computer Native Resolution 1024 x 768
- Computer Compatiblity XGA, SVGA, VGA & MAC
- Computer Formats Supported 1024x768, 800x600, 640x480
Video Specifications
- Video Input Systems Composite/Component: Y,Pb/Cb,Pr/Cr, S-Video (DVD & HDTV)
- Video Color Systems NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
- SDTV Compatibility 480i/p(60), 540p(60), 576i/p(50)
- HDTV Compatibility 720p(60), 1035i(50/60), 1080i(50/60)
- Video Native Resolution 720p
Connections
- On Input 3 - 4 pin DIN (S-Video) x 1 S-Video Input (Y/C)
- RCA x 1 (yellow) Video In (Composite)
- RCA x 3 (green, blue & red or Y, Cb/Pb, Cr/Pr) Video In (Component: Y,Pb/Cb,Pr/Cr)
Physical Specifications
- Cabinet Height 4.1"
- Cabinet Width 12.2"
- Cabinet Depth 11.3"
- Packaged Height 10.7"
- Packaged Width 16.3"
- Packaged Depth 15.8"
- Weight 9.5 lbs.
- Packaged Weight 8.0 kg
Electrical Specifications
- Power Management Auto Shut-Off
- Power Requirements 100-240V AC, 50/60Hz
- Power Consumption 360 Watts
Environment
- Operating Temperature - Max. 95 F
- Operating Temperature - Min. 41 F
- Generated Heat 1229 BTU/hr (310 Kcal/hr)
Eco-Mode Specifications
- Brightness (ECO Mode) - ANSI Lumens 960
- Operating Noise (ECO Mode) - dBA 32
- Power Consumption (ECO Mode) - Watts 320
- Generated Heat (ECO Mode) 1200 BTU/hr (276 Kcal/hr)
Security
- Kensington® Security Slot Cable Locking System
User Maintenance
- User maintenance Replace Lamp
Warranty
- Warranty - Unit (to original end-use customer) 3 Yr. / 6000 Hr.* (Parts/Labor to Correct Defects) * Whichever Occurs First
- Warranty - Lamp (to original end-use customer) 90 Days (Failed Lamp Replaced Pro-Rata)
Warning
- Mercury Warning Lamp contains Mercury. Do not put in trash. Dispose of as Hazardous Waste, according to Local, State or Federal Laws.
|
