Specifications: |
Controls
- Local Control: Record,play,review,cue/fast forward,pause,stop,eject
- Remote Pause: Yes
- Record Level Control: ALC LED meter
- LED Indicator: Red record level
Recording Specifications
- Tape Capacity: C-30, C-60, C-90.
- Tape Counter: Resettable 3- digit (ANSI 2x standard)
- Recording Heads: Record, playback, erase.
- Tape Format: Cassette, monaural.
- Tape Speed: 1 7/8" per sec.
- Rewind Time: C-60 1 minute, 50 seconds.
Audio Specifications
- Amplifier: 10 Watts (D.H.T. 10%)
- Heads: Record, Erase & Playback
- Speakers (Built-in): 1 x (3.93 x 5.12 in.)
- Wow & Flutter: 0.17%
- Signal To Noise Ratio: 45dB
- Frequency Response: 125Hz ~ 8KHz
- Internal Microphone: Electret condenser, omni directional monaural type
- Microphone Input: Miniature jacks
Connections
- 1/4" Phone Jack (4 ohm) x 1: Speaker jack
- 1/4" Phone Jack x 7: headset jacks
- mini: Remote Microphone Jack
- mini #2: Auxilary Input Jack
- submini: Remote Pause
Physical Specifications
- Type: Portable player/recorder
- Cabinet Height: 13"
- Cabinet Width: 9.48"
- Cabinet Depth: 3.97"
- Weight: 6.11 lbs
- Packaged Weight: 7.39 lbs
Electrical Specifications
- Power Requirements: 120V AC, 60Hz
- Power Consumption: 18 Watts
- Battery or AC Operation: AC only.
Safety
- Compliance: UL Listed
Warranty
- Warranty - Unit: 1-Year limited warranty of original purchase for parts and labor.
|
|
