Specifications: |
Controls
- Local Control: Record,play,review,cue/fast forward,pause,stop,eject
- Remote Pause: Yes
- Pause Control: Yes
- Record Level Control: Automatic level control (ALC)
Recording Specifications
- Tape Capacity: C-30, C-60, C-90
- Tape Format: Cassette, mono
- Recording Heads: Yes
- Tape Speed: 1 7/8 " per sec.
- Rewind Time: C-60 1 minute, 50 seconds
- Erasing Efficiency: 40 dB - 0 dB at 1KHz
Audio Specifications
- Amplifier: 1 watt RMS (T.H.D. 5%)
- Heads: Record, Erase & Playback
- Speakers (Built-in): 1 x 4 in. round
- Wow & Flutter: 0.30%
- Signal To Noise Ratio: 40 dB
- Frequency Response: 125Hz ~ 8KHz
- Internal Microphone: Electret condenser, omni directional monaural type
- Microphone Input: Miniature jacks
Connections
- 1/4" Phone Jack x 4: headset jacks
- 1/4" Phone Jack (4 ohm) x 1: Speaker jack
- mini Remote: Microphone Jack
- mini #2: Auxilary Input Jack
- submini: Remote Pause
Physical Specifications
- Type: Portable player/recorder
- Cabinet Height: 11.5"
- Cabinet Width: 7.87"
- Cabinet Depth: 2.75"
- Weight: 4 lbs
- Packaged Weight: 2.49 kg
Electrical Specifications
- Power Requirements: 120V AC, 60Hz, DC 120 Volts (6 "C" size batteries)
- Power Consumption: 10 Watts
- Battery or AC Operation: Battery (AC with adapter)
- Power Cord : 6', 3 prong (grounded) attached
Safety
- Compliance: UL Approved
Warranty
- Warranty - Unit: 1-Year limited warranty from date of original purchase for parts and labor
|
|
